bit 2-1-0:
1: not used
o
2: send DALI answer (8 bit data) (DATA_LO)
o
3: send DALI (16 Bit) (DATA_MID, DATA_LO)
o
4: send eD (25 bit data) (DATA_HI, DATA_MID, DATA_LO)
o
5: send DSI (8 bit data if DATA_MID = 0, else 16 bit data (DATA_MID, DATA_LO))
o
(***) Check Sum
XOR-combination of the previous 4 bytes (Control to DATA_LOW).
