MENU BAR
S :
ETUP
This section defines the connection's parameters to the Ethernet side of the HD67839 converter.
By Pressing the "Setup" button from the menu bar of the DALI Console software, the "SETUP" window appears (Fig. 9).
The means of the fields for the "SETUP" window are:
In the field "IP ADDRESS" insert the IP address set inside the converter;
In the field "DEVICE
'10000');
In the field "CONSOLE
SW67839);
In the fields "SCI X Protocol", it is possible to select the Ethernet protocol to use. It is possible to use SCI 1 (from Tridonic), SCI 2
(from Tridonic) or SCI 3 (from ADFweb.com);
In the fields "DALIX", it is possible to select the DALI version to use. It is possible to use DALI1 or DALI2;
If the option "DISABLE AUTOMATIC
only on Ethernet command;
If the option "AutoRefresh" is checked, the list of DALI devices is refreshed automatically;
In the field "NUM DEVICES" the number of DALI devices connected to the converter is defined.
ADFweb.com Srl – IT31010 – Mareno – Treviso
Figure 9: "Setup" window
PORT" insert the communication port used for the Ethernet communication with the converter (fixed to
PORT" insert the communication port used for the Ethernet communication with the converter (defined with
SCAN" is checked, the automatic scanning of DALI side is disabled. The DALI side is scanned
