Node ID Setting
These commands are used to program the ID Address on the DALI nodes. It is necessary to send them consecutively.
IMPORTANT: it is possible to connect a single DALI node to the HD67839 to program correctly the ID Node.
REQUEST 1
ADFweb.com Srl – IT31010 – Mareno – Treviso
Byte Number Description
1 0x00
2 0x10
3 0x00
4 0x00
5 0x00
6 0x02
7 0x04
8 Counter (increased for every command) (Hex)
9 0xD1
10 (DALI_ID_to_set << 1) + 1 (Hex)
11 0x40
