Generic DALI command
This command is used to send a generic DALI command to a DALI node, to a group or to the entire network.
REQUEST
The DALI ID can have different value in relation to the ADV to manage:
0 to 63 (0x00 to 0x3F) to manage a single DALI node;
64 to 79 (0x40 to 0x4F) to manage the Groups;
127 (0x7F) for broadcast.
RESPONSE
The converter can send back two type of messages:
"ANSWER=VAL" where 'VAL' is the answer from the DALI device;
"ANSWER NOT RECEIVED" if any answer is received from the DALI node.
ADFweb.com Srl – IT31010 – Mareno – Treviso
Byte Number Description
1 0x00
2 0x10
3 0x00
4 0x00
5 0x00
6 0x02
7 0x04
8 Counter (increased for every command) (Hex)
9 DALI ID + 0x80 (Hex)
10 DALI Command (from DALI specifications)
11 0x00
