DALI SCI3:

This set of simple HEX commands allows to send DALI commands for controlling and reading DALI devices and to program the network.
Dali network scanning
This command is used to get the informations from the DALI nodes configured in the network.
Note:
This command must be sent to the UDP port 10000.
REQUEST
Byte 0 Byte 1 Byte 2
Hex 0x44 0x41 0x4C
Text D A
RESPONSE
The converter sends back as response an array of data of 512 bytes. For each DALI node, 8 bytes are reserved. Here's the data mapping of
the data array sent:
ADFweb.com Srl – IT31010 – Mareno – Treviso
Byte 3 Byte 4 Byte 5
0x49 0x5F 0x49
L I _ I
User Manual DALI / Ethernet
Document code: MN67839_ENG
Byte 6 Byte 7 Byte 8 Byte9
0x4E 0x46 0x4F 0x3D
N F 0
