Scene Setting
This command is used to activate a programmed scene in a single DALI node, in a group or for the entire DALI network.
REQUEST
The DALI ID can have different value in relation to the ADV to manage:
0 to 63 (0x00 to 0x3F) to manage a single DALI node;
64 to 79 (0x40 to 0x4F) to manage the Groups;
127 (0x7F) for broadcast.
The Scene Number can have a value between 0 and 15.
ADFweb.com Srl – IT31010 – Mareno – Treviso
Byte Number Description
1 0x00
2 0x10
3 0x00
4 0x00
5 0x00
6 0x02
7 0x04
8 Counter (increased for every command) (Hex)
9 DALI ID + 0x80 (Hex)
10 Scene Number + 0x10 (Hex)
11 0x00
