CHARACTERISTICS:
The HD67116 is a RS485 / RS422 Converter.
They have the following characteristics:
Triple isolation between RS485 - Power Supply, RS485 – RS422, RS422 - Power Supply;
Two-directional information between RS485 bus and RS422 bus;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8...24V AC or 12...35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION:
You need Compositor SW67116 software on your PC in order to perform the following:
Define the parameters of RS485 line;
Define the parameters of RS422 line;
Update the device.
ADFweb.com Srl – IT31010 – Mareno – Treviso
User Manual RS485 / RS422 - Converter
Document code: MN67116_ENG
Revision 1.000
INFO:
www.adfweb.com
Phone +39.0438.30.91.31
Page 6 of 22
