S ...:
EARCH
This section is used to scan the DALI network and assign automatically the ID to the DALI nodes connected to the converter.
It is possible to reprogram the entire DALI network deleting and reprogramming the ID to all DALI devices ("Full Search") or set the ID only
to the DALI devices without it ("Partial Search").
DALI F :
ILE
In this section, it is possible to save or load the DALI devices' list.
T DALI 2:
EST
In this section it is possible to test DALI 2 devices (like sensors). It is possible to send commands or see the events from them.
The communication will start by pressing "Connect" button.
ADFweb.com Srl – IT31010 – Mareno – Treviso
Figure 10: "Test DALI 2" window
