Industrial Electronic Devices
CHARACTERISTICS:
The HD67614 is a DMX / PROFINET Converter.
It has the following characteristics:
Up to 512 bytes on DMX side;
Triple isolation between Ethernet - Power Supply, Ethernet – Serial, Power Supply - Serial.
Mountable on 35mm Rail DIN;
Wide power supply input range: 8...24V AC or 12...35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION:
You need Compositor SW67614 software on your PC in order to perform the following:
Define the parameter of PROFINET line;
Define the parameter of DMX line;
Define the map of PROFINET byte that must be written in DMX side;
Update the device.
ADFweb.com Srl – IT31010 – Mareno – Treviso
User Manual DMX / PROFINET
Document code: MN67614_ENG
INFO:
www.adfweb.com
Phone +39.0438.30.91.31
Revision 1.000
Pagina 6 di 22
