Connect pressure to the system (cont.)
c. Leave the Gauge Port plugged to prevent leakage or
attach a pressure gauge, as shown in
previous page.
NOTE NOTE
For side-mounted applications, the Gauge Port
can be used as the outlet. Plug the Outlet Port at the
CAUTION CAUTION
bottom of the controller for these applications.
WARNING WARNING
