ER5000 — The ERTune™ Program: Basic Features
To add a Control Limit for the ER5000 to monitor
Min
1. Enter a value in the
you wish to monitor and press the Tab key.
CAUTION
You must enter a value that is within the limits for the variable
you choose in order to activate it as a Control Limit.
The limits are:
Analog Setpoint: -12.12% – 111.97%
Internal Sensor: -12.12% – 111.97%
External Sensor: -12.12% – 111.97%
Internal Sensor: -12.12% – 111.97%
Inner Error: -124.08% – 124.08%
Outer Error: -124.08% – 124.08%
If you enter a value below the
filed will immediately revert to the default value and will
revert to Disabled when you click out of the field.
2. To monitor for both minimum and maximum limits, enter
values in both fields.
When you click in an entry field, the limit is
IMPORTANT! IMPORTANT!
displayed as the default value. You must change this value or the field
will revert to Disabled when you click out of it.
Max
or entry field of the variable that
Min Max
or above the limit, the
To remove a Control Limit
1. Enter a value that is beyond the limit for that field. It will
revert to Disabled when you click out of the field.
To remove all Control Limits
Disable All
1. Click the button.
To change the Control Limit Condition
1. Select a different condition from the drop-down list.
