ER5000 Series — Features and Specifications

ER5000 Series Part Numbering System

As Figure 1 indicates, several base styles are available, including a
compact OEM model for tight spaces where the NEMA 4 enclosure
isn't needed. Please consult with your TESCOM™ representative
for special modifications or requirements.
ER5 XX X X X – X
Base Style
00 Standard NEMA 4X
02 Integrated Double Piston*
04 OEM Style (No Cover)*
05 Hazardous Location Enclosure**
10 Integrated with 44-4000*
11 Integrated with 44-5200*
Internal Sensor Configuration
0 0–100 psig, 0.1% Accuracy
* Contact the factory for dimensions and specifications of these ER5000 Series models.
** Click this link to view all Hazardous Location certifications for ER5050 model.
Figure 1: Breakdown of the ER5000 Part Number
C v Configuration
1 Standard Valves, C v = 0.01
Analog Signal Type
I 4–20 mA / 1–5V DC
V 0–10V DC
Features
S Standard Features
F Enhanced Features

ER5000 Standard Features

• USB and RS485 communications
• USB cable with integrated strain relief***
• 1/8" NPTF Inlet and Exhaust Ports
• 1/2" SAE controlled Outlet Port
Adaptor fitting 1/2" SAE x 1/8" NPTF
•
• Maximum inlet pressure = 120 psig / 8.2 bar***
• 0–100 psig / 0–6.9 bar internal sensor
• ERTune program for Windows XP, VISTA, Windows 7 and
™
Windows 8
IMPORTANT! IMPORTANT!
Windows 8 users: In order to maintain compatibility
with previous Windows operating systems, the ERTune
the .NET Framework 3.5, which is not installed by default in Windows
8. If you are using Windows 8, you will need to download and install
.NET Framework 3.5 before installing the ERTune
also need to disable Driver Signature Enforcement to install the ER5000
driver. We have provided step-by-step instructions for both these tasks
in Appendix A: Setting up the ERTune™ Program on Windows 8
*** These features do not apply to ER5050 Hazardous Location model.
program uses
™
program. You may
™
PCs.
