ER5000 — Internal Variables

Table of ER5000 Internal Variables

Table 27: ER5000 Internal Variables
Variable Index and Name
00 - ID_INNER_ACTUAL_ERROR
01 - ID_AD_SETPOINT
02 - ID_TEMP_ADJUST
03 - ID_INNER_D_COEF1
04 - ID_INNER_D_COEF2
05 - ID_COMPENSATED_EXTERNAL_SENSOR
06 - ID_COMPENSATED_INTERNAL_SENSOR
07 - ID_RAW_EXTERNAL_SENSOR
08 - ID_RAW_INTERNAL_SENSOR
09 - ID_CONTROL_MODE
10 - ID_INNER_DERIVATIVE
11 - ID_INNER_EFFECTIVE_ERROR
12 - ID_PWM_SHUTOFF_FLAG
13 - ID_RTTASK_DELAY
14 - ID_OUTER_ACTUAL_ERROR
15 - RESERVED
16 - ID_OUTER_D_COEF1
17 - RESERVED
18 - ID_OUTER_EFFECTIVE_ERROR
19 - ID_INNER_SENSOR_MIN
20 - ID_INNER_SENSOR_MAX
21 - ID_OUTER_INTEGRAL_CONSTANT
22 - ID_OUTER_INTEGRAL_MAXIMUM
Access Type Range:Decimal Range:Hex
RO Signed -4095 : 4095 -0fff : 0fff
RO Unsigned 0 : 65535 0 : ffff
RW Unsigned 0 : 65535 0 : ffff
RW Signed -32768 : 32767 -8000 : 7fff
--- --- ---
RO Unsigned 0 : 65535 0 : ffff
RO Unsigned 0 : 65535 0 : ffff
RO Unsigned 0 : 65535 0 : ffff
RO Unsigned 0 : 65535 0 : ffff
RW Signed 0 : 3
RO Signed -32768 : 32767 -8000 : 7fff
RO Signed -32768 : 32767 -8000 : 7fff
RW Unsigned 0 : 1
RW Unsigned 0 : 65535 0 : ffff
RO Signed -4095 : 4095 -0fff : 0fff
--- --- ---
RW Signed -32768 : 32767 -8000 : 7fff
--- --- ---
RO Signed -32768 : 32767 -8000 : 7fff
RW Unsigned 0 : 4095 0 : 0fff
RW Unsigned 0 : 4095 0 : 0fff
RW Signed -32768 : 32767 -8000 : 7fff
RW Signed -32768 : 32767 -8000 : 7fff
Variable Index and Name
23 - ID_OUTER_INTEGRAL_SUM
24 - RESERVED
25 - ID_OUTER_PROPORTIONAL_CONSTANT
26 - ID_FACTORY_MIN_INLET
--- 27 - ID_FACTORY_MIN_EXHAUST
28 - ID_INNER_INTEGRAL_CONSTANT
29 - ID_INNER_INTEGRAL_MAXIMUM
30 - ID_INNER_INTEGRAL_SUM
31 - RESERVED
0 : 3 32 - RESERVED
33 - RESERVED
34 - ID_OUTPUT
0 : 1 35 - ID_INNER_PROPORTIONAL_CONSTANT
36 - ID_COMP_TEMP_SENSOR
37 - ID_SETPOINT
--- 38 - ID_RAW_TEMP_SENSOR
39 - ID_GAIN
--- 40 - ID_OSET
41 - ID_ARDG
42 - ID_NODE
43 - ID_SETPOINT_FLAG
44 - ID_FEEDBACK
45 - ID_PROFILE_LOOP_COUNT
Access Type Range:Decimal Range:Hex
RW Signed -32768 : 32767 -8000 : 7fff
--- --- ---
RW Signed -32768 : 32767 -8000 : 7fff
RW Unsigned 0 : 250 0 : fa
RW Unsigned 0 : 250 0 : fa
RW Signed -32768 : 32767 -8000 : 7fff
RW Signed -32768 : 32767 -8000 : 7fff
RW Signed -32768 : 32767 -8000 : 7fff
--- --- ---
--- --- ---
--- --- ---
RO Signed -32768 : 32767 -8000 : 7fff
RW Signed -32768 : 32767 -8000 : 7fff
RO Unsigned 0 : 65535 0 : ffff
RW Unsigned 0 : 4095 0 : 0fff
RO Unsigned 0 : 4095 0 : 0fff
RW Unsigned 0 : 65535 0 : ffff
RW Unsigned 0 : 65535 0 : ffff
RO Unsigned 0 : 65535 0 : ffff
RW Unsigned 1 : 250 1 : fa
RW Signed 0 : 4
RO Unsigned 0 : 4095 0 : 0fff
RO Unsigned 0 : 30000 0 : 7530
---
---
---
---
0 : 4
