4. Parameter Descriptions
6-81 LCP Potmeter Low Ref. Value
Range:
0.000
6-82 LCP Potmeter High Ref. Value
4
Range:
50.00

4.7.6. 6-9* Analog Output

These parameters are for configuring the analog outputs of the frequency converter.
6-90 Terminal 42 Mode
Option:
[0]
[1]
[2]
6-91 Terminal 42 Analog Output
Option:
[0]
[10]
[11]
[12]
[13]
[16]
[17]
6-92 Terminal 42 Digital Output
Option:
[80]
48
* [-4999 - 4999]
* [-4999 - 4999]
* 0 - 20 mA
4-20 mA
Digital
* No Operation
Output Frequency
Reference
Feedback
Motor Current
Power
Speed
SL Digital Output A
MG.02.C2.02 - VLT
Function:
The scaling value corresponding to 0.
Enter low reference value.
The reference value corresponding to potentiometer turned fully
counterclockwise (0 degrees).
Function:
The scaling value corresponding to the maximum reference
feedback value set in par. 3-03.
Enter high reference value.
The reference value corresponding to potentiometer turned fully
clockwise (200 degrees).
Function:
Range for analog outputs is 0-20 mA
Range for analog outputs is 4 - 20 mA
Functions as slow reacting digital output. Set value to either 0
mA (off) or 20 mA (on), see par. 6-92.
Function:
Select the function for terminal 42 as an analog output.
Function:
Relays
See par. 5-4*, , for choices and descriptions.
SL Control Action
See par. 13-52
dig. out. A high
[38] is executed, input goes high. When Smart
Set dig. out. A low
Logic Action
® is a registered Danfoss trademark
VLT Micro Drive FC 51
. When Smart Logic Action
[32] is executed, input goes low.
Set
