4. Parameter Descriptions

13-52 SL Controller Action

Array [20]
[0]
[1]
[2]
4
[3]
[10]
[11]
[12]
[13]
[14]
[15]
[16]
[17]
[18]
[19]
[22]
[23]
[24]
[25]
[26]
[27]
[28]
[29]
[30]
[31]
[32]
[33]
[38]
[39]
[60]
[61]
64
* Disabled
No Action
Select Set-up1
Select Set-up2
SelectPresetRef0
SelectPresetRef1
SelectPresetRef2
SelectPresetRef3
SelectPresetRef4
SelectPresetRef5
SelectPresetRef6
SelectPresetRef7
SelectRamp1
SelectRamp2
Run
RunReverse
Stop
Qstop
DCstop
Coast
Freeze Output
StartTimer0
StartTimer1
StartTimer2
SetDO42Low
SetRelayLow
SetDO42High
SetRelayHigh
ResetCounterA
ResetCounterB
MG.02.C2.02 - VLT
Select action corresponding to SLC event. Actions are executed
when corresponding event (par. 13-51) is evaluated as
Function is disabled.
No action is taken.
Changes active set-up to Set-up 1.
Changes active set-up to Set-up 2.
Selects preset reference 0
Selects preset reference 1
Selects preset reference 2
Selects preset reference 3
Selects preset reference 4
Selects preset reference 5
Selects preset reference 6
Selects preset reference 7
Selects ramp 1
Selects ramp 2
Issues start command to frequency converter.
Issues start reverse command to frequency converter.
Issues stop command to frequency converter.
Issues quick stop command to frequency converter.
Issues DC stop command to frequency converter.
Frequency converter coasts immediately. All stop commands in-
cluding coast command stop the SLC.
Freezes output frequency.
Starts timer 0.
Starts timer 1
Starts timer 2
Digital output 42 is low.
Relay is low.
Digital output 42 is high.
Relay is high.
Resets counter A to 0.
Resets counter B to 0.
® is a registered Danfoss trademark
VLT Micro Drive FC 51
True .
