4. Parameter Descriptions
[39]
[40]

13-03 Reset SLC

Option:
[0]
4
[1]

4.10.3. 13-1* Comparators

Comparators are used for comparing continuous variables (i.e. output frequency, output current,
analog input etc.) to fixed preset values. In addition, there are digital values that will be compared
to fixed time values. See explanation in par. 13-10. Comparators are evaluated once in each scan
interval. Use the result (TRUE or FALSE) directly. All parameters in this parameter group are array
parameters with index 0 to 5. Select index 0 to programme Comparator 0, select index 1 to pro-
gramme Comparator 1, and so on.

13-10 Comparator Operand

Array [4]
[0]
[1]
[2]
[3]
[4]
[6]
[7]
[8]
[9]
[10]
[11]
[12]
[13]
[18]
[20]
[30]
[31]
60
StartCommand
* DriveStopped
* Do Not Reset
Reset SLC
* Disabled
Reference
Feedback
MotorSpeed
MotorCurrent
MotorPower
MotorVoltage
DCLinkVoltage
MotorThermal
DriveThermal
HeatSink Tempera-
ture
AnalogInput53
AnalogInput60
PulseInput33
AlarmNumber
CounterA
CounterB
MG.02.C2.02 - VLT
True
This event is , if frequency converter is started by any
means (digital input or other).
True
This event is , if frequency converter is stopped or coasted
by any means (digital input or other).
Function:
Retains all settings programmed in parameter group 13.
Reset all group 13 parameters to default settings.
Select variable to be monitored by comparator.
Comparator is disabled.
Resulting remote reference (not local) as a percentage.
Feedback in either [RPM] or [Hz].
Motor speed in Hz.
Motor current in [A].
Motor power in either [kW] or [Hz].
Motor voltage in [V].
DC-link voltage in [V].
Expressed as a percentage.
Expressed as a percentage.
Expressed as a percentage.
Expressed as a percentage.
Expressed as a percentage.
Expressed as a percentage.
Shows number of the alarm.
Number of counts.
Number of counts.
