4. Parameter Descriptions
6-14 Terminal 53 Low Ref./Feedb. Value
Range:
0.000
6-15 Terminal 53 High Ref./Feedb. Value
Range:
4
50.00
6-16 Terminal 53 Filter Time Constant
Range:
0.001 s
6-19 Terminal 53 Mode
Option:
[0]
[1]

4.7.4. 6-2* Analog Input 2

Parameters for configuring scaling and limits for analog input 2, terminal 60.
6-22 Terminal 60 Low Current
Range:
0.14
mA
46
* [-4999 - 4999]
* [-4999 - 4999]
* [0.001 - 10.00 s]
NB!
This parameter cannot be adjust while motor is running.
* Voltage Mode
Current Mode
[0.00 - 19.90 mA]
*
MG.02.C2.02 - VLT
Function:
The scaling value corresponding to the low voltage/low current
set in parameters 6-10 and 6-12.
Enter analog input scaling value.
Function:
The scaling value corresponding to the maximum reference
feedback value set in parameters 6-11 and 6-13.
Enter analog input scaling value.
Function:
A first-order digital low pass filter time constant for suppressing
electrical noise in terminal 53. A high time constant value im-
proves dampening but also increases time delay through the
filter.
Enter time constant.
Function:
Select the input to be present on terminal 53.
Par. 6-19 MUST be set according to Micro switch
4 setting.
Function:
This reference signal should correspond to minimum reference
value set in par. 3-02.
Enter low current value.
