VLT Micro Drive FC 51
[65]
5-10 Terminal 18 Digital Input
Option:
*
[8]
5-11 Terminal 19 Digital Input
Option:
[10]
5-12 Terminal 27 Digital Input
Option:
*
[0]
5-13 Terminal 29 Digital Input
Option:
[14]
5-15 Terminal 33 Digital Input
Option:
*
[0]

4.6.3. 5-4* Relays

Parameter group for configuring timing and output functions for relays.
[0]
[1]
[2]
[3]
[4]
[5]
[6]
[7]
Reset counter B Input for reset of counter B.
Function:
Start Select function from available digital input range.
See par. 5-1* for choices.
Function:
* Reversing Select function from available digital input range.
See par. 5-1* for choices.
Function:
No Operation Select function from available digital input range.
See par. 5-1* for choices.
Function:
* Jog Select function from available digital input range.
See par. 5-1* for choices.
Function:
No Operation Select function from available digital input range.
See par. 5-1* for choices.
No Operation Default for all digital and relay outputs.
Control Ready Control board receives supply voltage.
Drive Ready Frequency converter is ready for operation and applies supply
signal on control board.
Drive Ready, Remote Frequency converter is ready for operation in Auto On-mode.
Enable/No Warning Frequency converter is ready for operation. No start or stop
command is given. No warnings are present.
Drive Running Motor is running.
Running/No Warning Motor runs, and no warning are present.
Run in Range/No Motor runs within programmed current ranges, see parameters
Warning 4-50 and 4-51. No warnings are present.
