Ramp2 - Danfoss VLT FC 51 Series Programming Manual

4. Parameter Descriptions
3-40 Ramp1 Type
Option:
[0]
[2]
3-41 Ramp1 Ramp-up Time
Range:
3.00 s
4
3-42 Ramp1 Ramp-down Time
Range:
3.00

4.4.5. 3-5* Ramp2

See par. 3-4* for a description of ramp types.
3-50 Ramp2 Type
Option:
[0]
[2]
3-51 Ramp2 Ramp-up Time
Range:
3.000
3-52 Ramp2 Ramp-down Time
Range:
3.000 s [0.100 - 3600 s]
34
* Linear
S-ramp
* [0.05 - 3600 s ]
* [0.05 - 3600 s]
NB!
Ramp2 - alternative ramp times:
Changing from Ramp1 to Ramp2 is done via the digital input. See par. 5-1*, selection
[34].
* Linear
S-ramp
*
[0.100 - 3600 s]
MG.02.C2.02 - VLT
Function:
Constant acceleration/deceleration.
Smooth jerk compensated acceleration/deceleration.
Function:
Enter ramp-up time from 0 Hz to rated motor frequency (f
set in par. 1-23.
Choose a ramp-up time ensuring that torque limit is not excee-
ded, see par. 4-16.
Function:
Enter ramp down time from rated motor frequency (f
1-23 to 0 Hz.
Choose a ramp down time that does not cause over-voltage in
inverter due to regenerative operation of motor. Furthermore,
regenerative torque must not exceed limit set in par. 4-17.
Function:
Constant acceleration/deceleration.
Smooth jerk compensated acceleration/deceleration.
Function:
Enter ramp-up time from 0 Hz to rated motor frequency (f
set in par. 1-23.
Choose a ramp-up time ensuring that output current does not
exceed current limit set in par. 4-18 during ramping.
Function:
Enter ramp down time from rated motor frequency (f
1-23 to 0 Hz.
® is a registered Danfoss trademark
VLT Micro Drive FC 51
)
M,N
) in par.
M,N
)
M,N
) in par.
M,N
