Logic Rule Operator 1 - Danfoss VLT FC 51 Series Programming Manual

4. Parameter Descriptions
[4]
[7]
[8]
[9]
[16]
[17]
4
[18]
[19]
[20]
[21]
[22]
[23]
[24]
[25]
[26]
[27]
[28]
[29]
[30]
[31]
[32]
[33]
[34]
[35]
[36]
[39]
[40]

13-41 Logic Rule Operator 1

Array [4]
[0]
[1]
[2]
62
OnReference
BelowILow
AboveIHigh
ThermalWarning
MainsOutOfRange
Reversing
Warning
Alarm_Trip
Alarm_TripLock
Comparator 0
Comparator 1
Comparator 2
Comparator 3
LogicRule 0
LogicRule 1
LogicRule 2
LogicRule 3
SL Timeout0
SL Timeout1
SL Timeout2
DigitalInput_18
DigitalInput_19
DigitalInput_27
DigitalInput_29
StartCommand
DriveStopped
* Disabled
And
Or
MG.02.C2.02 - VLT
See par. 5-4* [8] for description.
See par. 5-4* [12] for description.
See par. 5-4* [13] for description.
See par. 5-4* [14] for description.
See par. 5-4* [21] for description.
Mains voltage is outside the specified voltage range.
See par. 5-4* [25] for description.
A warning is active.
A trip alarm is active.
A trip lock alarm is active.
Use result of comparator 0 in logic rule.
Use result of comparator 1 in logic rule.
Use result of comparator 2 in logic rule.
Use result of comparator 3 in logic rule.
Use result of logic rule 0 in logic rule.
Use result of logic rule 1 in logic rule.
Use result of logic rule 2 in logic rule.
Use result of logic rule 3 in logic rule.
Use result of timer 0 in logic rule.
Use result of timer 1 in logic rule.
Use result of timer 2 in logic rule.
Use value of DI 18 in logic rule.
Use value of DI 19 in logic rule.
Use value of DI 27 in logic rule.
Use value of DI 29 in logic rule.
This event is True , if frequency converter is started by any
means (digital input or other).
This event is True , if frequency converter is stopped or coasted
by any means (digital input or other).
Select first logical operator to use on boolean inputs from par.
13-40 and 13-42.
Ignores parameters 13-42, 13-43 and 13-44.
Evaluates expression [13-40] AND [13-42].
Evaluates expression [13-40] OR [13-42].
® is a registered Danfoss trademark
VLT Micro Drive FC 51
