4. Parameter Descriptions

4.8. Parameter Group 7: Controllers

4.8.1. 7-** Controllers
Parameters group for configuring application controls.

4.8.2. 7-2* Process Ctrl. Feedb

Select feedback sources and handling for Process PI Control.
4

7-20 Process CL Feedback Resources

Option:
[0]
[1]
[2]
[8]
[11]

4.8.3. 7-3* Process PI Control

7-30 Process PI Normal/Inverse Control
Option:
[0]
[1]
7-31 Process PI Anti Windup
Option:
[0]
[1]
7-32 Process PI Start Speed
Range:
0.0 Hz
7-33 Process PI Proportional Gain
Option:
[0.01]
50
* No Function
Analog Input 53
Analog Input 60
Pulse Input 33
Local Bus Ref.
* Normal
Inverse
Disable
*
Enable
*
[0.0 - 200.0 Hz]
*
0.00 - 10.00
MG.02.C2.02 - VLT
Function:
Select input to function as feedback signal.
Function:
Feedback larger than setpoint result in a speed reduction.
Feedback less than setpoint result in a speed increase.
Feedback larger than setpoint result in a speed increase.
Feedback less than setpoint result in a speed reduction.
Function:
Regulation of a given error will continue even when the output
frequency cannot be increased/decreased.
PI-controller ceases from regulating a given error when the out-
put frequency cannot be increased/decreased.
Function:
Until the set motor speed has been reached the frequency con-
verter operates in Open Loop mode.
Function:
Enter the value for the P proportional gain, i.e. the multiplication
factor of the error between the set point and the feedback sig-
nal.
Note! 0.00 = Off.
