Danfoss VLT AutomationDrive FC 301 Design Manual page 102

How to Order
FC 302
T5
PK37
PK55
PK75
P1K1
P1K5
P2K2
P3K0
P4K0
P5K5
P7K5
P11K
P15K
7 7 Table 7.20 Other Flat Packs for Frequency Converters with Mains Supply
FC 302 Mains: 380-500 V (T5)
IP65 is a flat pack type with fixed cable.
100
®
VLT AutomationDrive FC 301/FC 302 Design Guide, 0.25-75 kW
P R R
m min
[kW] [Ω]
0.37 620 1389
0.55 620
0.75 558
1.1 382
1.5 260.0 325.9
2.2 189.0 218.6
3 135.0 158.5
4 99
5.5 72
7.5 50
11 36.0
15 27.0
MG33BF02 - Rev. 2013-12-20
Flat pack IP65 for horizontal conveyors
R per item
br. nom rec
[Ω] [Ω/W]
830/100
929 830/100
678 620/100 or 620/200
453 430/100 or 430/200
310/200
210/200
150/200 or 300/200
117 240/200
84 160/200
61 130/200
41.2 80/240
30.0 72/240
Duty cycle Ordering no.
[%] 175Uxxxx
30 1000
20 1000
14 or 27 1001 or 0982
10 or 20 1002 or 0983
14 0984
10 0987
7 or 14 0989 or 2 x 0985
10 2 x 0986
8 2 x 0988
6 2 x 0990
5 2 x 0090
4 2 x 0091
