Basic Operating Principles
The size of the dead band is defined by either P1 or P2 as
shown in Illustration 3.19.
Quadrant 2
3 3
High reference/feedback
value
Low reference/feedback
value
-10 -6
Quadrant 3
Illustration 3.19 Dead Band
Quadrant 2
High reference/feedback
value
-10 -6
Terminal X
low
Quadrant 3
Illustration 3.20 Reverse Dead Band
Thus a reference endpoint of P1 = (0 V, 0 RPM) does not
result in any dead band, but a reference endpoint of e.g.
P1 = (1 V, 0 RPM) results in a -1 V to +1 V dead band in
this case provided that the end point P2 is placed in either
Quadrant 1 or Quadrant 4.
32
Resource output
(RPM)
P2
1500
Resource
input
0 P1
-1 1 6
Terminal X Terminal X
low high
-1500
Resource output
(RPM)
1500
Low reference/feedback
P1
value
Resource
P2 0
input
-1 1 6
Terminal X
high
-1500
®
