Danfoss VLT AutomationDrive FC 301 Design Manual page 81

Product Specifications
Mains
Cable voltage Rise time
[μs]
length [m] [V]
36 240 0.264
136 240 0.536
150 240 0.568
Table 6.14 P7K5T2
Mains
Cable voltage Rise time
length [m] [V] [μs]
30 240 0.556
100 240 0.592
150 240 0.708
Table 6.15 P11KT2
Mains
Cable voltage Rise time
length [m] [V] [μs]
36 240 0.244
136 240 0.568
150 240 0.720
Table 6.16 P15KT2
Mains
Rise time
Cable voltage
length [m] [V] [μs]
36 240 0.244
136 240 0.568
150 240 0.720
Table 6.17 P18KT2
Mains
Rise time
Cable voltage
length [m] [V] [μs]
15 240 0.194
50 240 0.252
150 240 0.488
Table 6.18 P22KT2
Mains
Rise time
Cable voltage
length [m] [V] [μs]
30 240 0.300
100 240 0.536
150 240 0.776
Table 6.19 P30KT2
®
VLT AutomationDrive FC 301/FC 302 Design Guide, 0.25-75 kW
Upeak
dU/dt [kV/μs]
[kV]
0.624 1.890
0.596 0.889
0.568 0.800
Upeak dU/dt
[kV] [kV/μs]
0.650 0.935
0.594 0.802
0.587 0.663
Upeak dU/dt
[kV] [kV/μs]
0.608 1.993
0.580 0.816
0.574 0.637
dU/dt
Upeak
[kV] [kV/μs]
0.608 1.993
0.580 0.816
0.574 0.637
dU/dt
Upeak
[kV] [kV/μs]
0.626 2.581
0.574 1.822
0.538 0.882
dU/dt
Upeak
[kV] [kV/μs]
0.598 1.594
0.566 0.844
0.546 0.562
MG33BF02 - Rev. 2013-12-20
Mains
Cable voltage Rise time
[μs]
length [m] [V]
30 240 0.300
100 240 0.536
150 240 0.776
Table 6.20 P37KT2
380-500 V (T4)
Mains
Rise time
Cable voltage
length [m] [V] [μs]
5 480 0.640
50 480 0.470
150 480 0.760
Table 6.21 P1K5T4
Mains
Rise time
Cable voltage
length [m] [V] [μs]
5 480 0.172
50 480 0.310
150 480 0.370
Table 6.22 P4K0T4
Mains
Rise time
Cable voltage
length [m] [V] [μs]
5 480 0.04755
50 480 0.207
150 480 0.6742
Table 6.23 P7K5T4
Mains
Cable voltage Rise time
[μs]
length [m] [V]
36 480 0.396
100 480 0.844
150 480 0.696
Table 6.24 P11KT4
Mains
Cable voltage Rise time
length [m] [V] [μs]
36 480 0.396
100 480 0.844
150 480 0.696
Table 6.25 P15KT4
Upeak dU/dt
[kV/μs]
[kV]
0.598 1.594
0.566 0.844
0.546 0.562
dU/dt
Upeak
[kV] [kV/μs]
0.690 0.862
0.985 0.985
1.045 0.947
dU/dt
Upeak
[kV] [kV/μs]
0.890 4.156
2.564
1.190 1.770
dU/dt
Upeak
[kV] [kV/μs]
0.739 8.035
4.548
1.030 2.828
Upeak dU/dt
[kV/μs]
[kV]
1.210 2.444
1.230 1.165
1.160 1.333
Upeak dU/dt
[kV] [kV/μs]
1.210 2.444
1.230 1.165
1.160 1.333
