Danfoss VLT AutomationDrive FC 301 Design Manual page 174

Options and Accessories
Enclosure type
A2
A3
B3
B4
C3
C4
Table 11.13 Dimensions
* If option A/B is used, the depth increases (see
chapter 8.2.1 Mechanical Dimensions for details)
B
11 11
D
E
Illustration 11.25 Enclosure Type B3
172
VLT
Height A Width B
[mm] [mm]
372 90
372 130
475 165
670 255
755 329
950 391
A
C
®
AutomationDrive FC 301/FC 302 Design Guide, 0.25-75 kW
Depth C*
A
[mm]
205
205
249
246
337
337
D
F
Illustration 11.26 Enclosure Types B4 - C3 - C4
A Top cover
B Brim
C Base part
D Base cover
E Screw(s)
F Fan cover
G Top clip
Table 11.14 Legend to Illustration 11.25 and Illustration 11.25
MG33BF02 - Rev. 2013-12-20
C
G
