Maintenance
•
Remove the sump guard
•
Remove the manifold-terminal
•
Place a container of suitable capacity
under the drain plug (1).
•
Unscrew and remove the drain plug
(1).
•
Unscrew and remove the filler plug (2).
•
Drain the oil into the container; allow
several minutes for oil to drain out com-
pletely.
•
Check and if necessary, replace the
sealing washers of drainage plug (1).
•
Remove any metal deposits attached
to the drainage plug (1) magnet.
•
Pour in new oil, observing the quantity
indicated in the "Capacity" table
CAUTION
DO NOT ADD ADDITIVES OR OTHER SUBSTANCES TO
THE FLUID. WHEN USING A FUNNEL OR ANY OTHER EL-
EMENT, MAKE SURE IT IS PERFECTLY CLEAN.

Air filter

REMOVAL
•
Remove the saddle
•
Remove the glove compartment
•
Remove the side fairing panels
•
Unhook and remove the four springs
(1) located around the airbox filter, two
in the upper area, one on the left side
and one on the right side
