Field Field description
Active The number of active conferences that this
conferences TelePresence Server is controlling.
Active The number of endpoints (of all types) that
endpoints are in active conferences controlled by this
TelePresence Server.
Video ports The number of video ports in use. The
second number is the maximum on this
TelePresence Server.
Audio ports The number of audio-only ports in use. The
second number is the maximum on this
TelePresence Server.
Content ports The number of content channel ports in use.
The second number is the maximum on this
TelePresence Server.
Field Field description
The system log displays the most recent
shutdown and upgrade events, with the
most recent shown first.
Field Field description
Diagnostic Diagnostic files are provided in .zip archive
information format that contain a text document. To
download a diagnostic file, click Download
file.
Network To download a network capture, click
capture file Download file.
System logs To download the logs, click Download file.
Cisco TelePresence Server Product User Guide
Usage tips
If this is the Conference controller, then this
is the number of active conferences across
all managed TelePresence Servers. A
TelePresence Server that is not the
Conference controller will show 0 here.
For more information, see
Conference
If this is the Conference controller, then this
is the number of endpoints in active
conferences across all managed
TelePresence Servers. A TelePresence
Server that is not the Conference controller
will show 0 here.
For more information, see
Conference
If this is the Conference controller, the
numbers are those across all managed
TelePresence Servers controlled by this
TelePresence Server. A TelePresence
Server that is not the Conference controller
will show 0 here.
For more information, see
Conference controller
video
System log
Usage tips
The log will display "unknown" if there has
been an unexpected reboot or power failure.
If this occurs frequently, report the issues to
customer support.
Diagnostic information
Usage tips
Diagnostic information is provided to aid in
troubleshooting problems that may occur
with the TelePresence Server.
In the event of an issue with the
TelePresence Server, the support team may
ask you for these diagnostic files.
The network capture file is only available on
the master blade in a TelePresence Server
cluster.
An archive containing several useful log files.
Understanding the
controller.
Understanding the
controller.
Understanding the
and Content channel
support.
System status
