Field Field description
HD mode Defines the maximum video definition that
the TelePresence Server will support.
One of HD or Full HD.
If you change this setting, your change will
take effect as soon as there are no
participants connected to the TelePresence
Server.
Call out using Allows the TelePresence Server to display
conference the conference name to identify itself when
name calling out to participants.
Call out to If this option is selected, if a call is received
grouped from an endpoint which forms part of a
endpoints if manually-configured group the
one calls in TelePresence Server will call out to the other
endpoints in that group.
Automatic Whether a participant is allowed to interrupt
content another participant's presentation in a
handover conference by starting one of their own.
This is unselected by default.
Indicate Whether an overlaid icon is shown on video
presence of participants' screens to show the presence
audio-only of audio-only participants in the conference.
participants This is unselected by default.
Display video When selected, thumbnail preview images
preview of conference participants' video streams
images are shown on the TelePresence Server
user interface.
Cisco TelePresence Server Product User Guide
Usage tips
HD mode supports a maximum definition of
720p at 30fps, or w448p at 60 fps.
Full HD mode supports a maximum definition
of 1080p at 30 fps, or 720p at 60 fps.
An endpoint that uses Full HD mode
consumes more of the TelePresence Server
resources than one using HD mode. This
affects the maximum number of Full
HD participants; see ports allocation
details.
Disabled by default. May not be displayed by
all endpoints.
You should make sure this option is
unchecked if the endpoints which make up
manually-configured groups are set to call in
together - in this case the TelePresence
Server will recognise the separate calls and
group them automatically.
When selected, if an endpoint attempts to
send content when another participant is
already sending content, the endpoint would
override or cancel any existing presentation.
When selected, a telephone icon is
displayed in the top left-hand corner of the
screen with a number next to it showing the
number of audio-only participants present.
For grouped endpoints, the icon is shown on
just one of the screens:
the middle screen on T3s and Experias
n
for manually-configured groups, on the
n
screen configured as the Screen to
receive content / audio in the group's
Advanced settings.
Configuration
for more
