Tab. 2-2 Dimensions and Weight
Type
SG2K-S / SG2K5-S /
SG3K-S
SG3K-D / SG5K-D
SG8K-D
LCD Panel
The LCD panel with a screen, an indicator and two buttons is on the front of the
inverter.
No. Name
1 LCD
screen
2 Buttons
3 Indicator

2.3 Energy Meter (optional)

The SUNGROW Energy Meter is installed next to the main switch to detect the
electrical measured values at the grid-connected point. It communicates with
the inverter via an RS485 connection. The dimensions are shown below.
W (mm)
300
360
360
Fig. 2-4 LCD Panel
Description
Display and access current operating data or change inverter
settings.
ESC / ENT.
View or set parameters via the buttons. For detailed
functions, see Tab. 6-1.
Green / red.
User can observe the colour and blinking frequency to get
the current state of the inverter. For detailed definition, see
Tab. 6-2.
H (mm) D (mm)
370 125
390 133
390 148
1 2 3
2 Product Introduction
Weight (kg)
8.5
11.5
15.5
