User Manual
Hydraulic plier
Wire clipper
Torx screwdriver
TX30

4.4 Installing the Inverter

Inverter is installed on the wall by means of wall-mounting bracket and the
expansion plug sets.
The expansion plug set shown below is recommended for the installation. They
are not included in the delivery scope.
Stainless steel screw M6
Wire crimper
Crimping
2.5-6mm²
RJ11 crimping tool
Socket wrench
Open end: 10mm (for
M6 bolts)
13mm (for M8 bolts)
16mm (for M10 bolts)
Expansion tube
4 Mechanical Mounting
Wrench
terminal
range:
Flat-blade screwdriver
M4
Fender washer
for MC4
Spring washer
19
