5.7 DRM Connection to an External Device

The cable for connecting to the DRED is not included in the delivery.
Use a TIA/EIA 568B standard network cable with a diameter of 3 mm
1. Take out the communication
connector
packaging, as shown on the
right.
2. Loosen the screws and
remove the waterproof lid
from the
terminal.
Note:
Retain the screws for later
installation.
external demand
secure the
from the
