7 LCD Operation

7.4 Viewing Running Info

Proceed as follows to look through the detailed running information.
Main Screen (Press ENT)→Menu→Run Info (Press ENT)
Scroll pages by touching ENT / ESC.
E-today:
E-total:
Meter Power:
P Limit:
max
Meter power:
+ (omitted): The inverter is sourcing power to the grid.
-: The inverter is sinking power from the grid.
P limit: only indicated for the derating in the event of over-temperature,
max
overvoltage or over-frequency.

7.5 Advanced Settings

7.5.1 Inputting the Password

The parameter settings are protected with a password. If you want to set the
inverter's parameters, you have to input the correct password.
Main Screen (Press ENT)→Menu (Touch ESC)→Settings (Press ENT)
Touch ESC to add the value and
Touch ENT to move the cursor.
Input the password 111.
Press ENT to confirm the password and enter the submenu.
Touch ESC to navigate down and Press ENT to confirm.

7.5.2 Setting Protective Parameters

Protective parameters are designed for the threshold values that can trigger the
protective function of the inverter. The threshold values are compliant with the
requirements of local safety standards and the utility grid.
