PS_DDR_VRN, PS_DDR_VRP – PS DDR Termination Voltage
PS_DDR_VRN and PS_DDR_VRP provide a reference for digitally controlled impedance (DCI)
calibration. For memory types that require termination (DDR2, DDR3) VRP must be pulled
Low to GND and VRN needs to be pulled High to V
on VRP and VRN should be twice the memory's trace and termination impedance. For
example, for a DDR3 memory with a 40Ω termination and board impedance, an 80Ω resistor
must be used to pull-up/down VRP and VRN. For LPDDR2, the DCI tunes the output
impedance of the driver and therefore the resistor value on VRP and VRN should be equal
to the transmission line impedance, typically set to 40Ω.
Table 5-2 shows the required values for the DCI VRN/VRP pull-down/pull-up resistors.
Table 5-2: DCI VRP and VRN Values
VRP/VRN

Unused DDR Memory

When no PS DDR memory is used, V
and PS_DDR_VRN/P should be left floating.

PS MIO Power Supplies

V – PS MIO Bank 0 I/O Supply
CCO_MIO0
V is a 1.8–3.3 volt supply. It powers I/O Bank 500 which contains PS_MIO[15:0],
CCO_MIO0
PS_CLK, and PS_POR_B I/Os.
V – PS MIO Bank 1 I/O Supply
CCO_MIO1
V is a 1.8-3.3 volt supply. It powers I/O Bank 501 which contains PS_MIO[53:16],
CCO_MIO1
PS_VREF_MIO, and PS_SRST_B I/Os.
Configuring the V
The PS I/O banks can operate in two different voltage modes, low (1.8V) mode and high
(2.5V – 3.3V) mode. Before powering on, the banks must be configured for the correct mode
otherwise, damage might occur. The I/O bank voltage is set by pulling pins MIO[7] and
MIO[8] either High or Low.
MIO Bank 0 and Bank 1.
