• Both mounting inductances are reduced by placing power planes close to the PCB
stackup's top half and placing the capacitors on the top surface (reducing the
capacitor's via length).
• If power planes are placed in the PCB stackup's bottom half, the capacitors must be
mounted on the PCB backside. In this case, AP SoC mounting vias are already long, and
making the capacitor vias long (by coming down from the top surface) is a bad
practice. A better practice is to take advantage of the short distance between the
underside of the PCB and the power plane of interest, mounting capacitors on the
underside.

PCB Stackup and Layer Order

V and ground plane placement in the PCB stackup (the layer order) has a significant
CC
impact on the parasitic inductances of power current paths. Layer order must be considered
early in the design process:
• High-priority supplies should be placed closer to the AP SoC (in the PCB stackup's top
half)
• Low-priority supplies should be placed farther from the AP SoC (in the PCB stackup's
bottom half)
Power supplies with high transient current should have the associated V
the top surface (AP SoC side) of the PCB stackup. This decreases the vertical distance (V
and GND via length) that currents travel before reaching the associated V
planes. To reduce spreading inductance, every V
plane in the PCB stackup. The skin effect causes high-frequency currents to couple tightly,
and the GND plane adjacent to a specific V
current complementary to that in the V
treated as a pair.
Not all V and GND plane pairs reside in the PCB stackup's top half because manufacturing
CC
constraints typically require a symmetrical PCB stackup around the center (with respect to
dielectric thicknesses and etched copper areas). The PCB designer chooses the priority of
the V and GND plane pairs: high priority pairs carry high transient currents and are placed
CC
high in the stackup, while low priority pairs carry lower transient currents (or can tolerate
more noise) and are placed in the lower part of the stackup.

Capacitor Effective Frequency

Every capacitor has a narrow frequency band where it is most effective as a decoupling
capacitor. This band is centered at the capacitor's self-resonant frequency F
effective frequency bands of some capacitors are wider than others. A capacitor's ESR
determines the capacitor's quality (Q) factor, and the Q factor can determine the width of
the effective frequency band:
• Tantalum capacitors generally have a very wide effective band.
