Digital Output Connection
Output voltage
Max. load current
Figure 4-18
4-30
DigOUT1 "Source" Circuit (analogously valid also for DigOUT2)
Document ID: rel7050
Edition: May 2017
© 2017 maxon motor. Subject to change without prior notice.
DigOUT "Source"
≈5 V − 0.75 V − (I
U
out
≤2 mA
I
load
EPOS2 Module 36/2 Hardware Reference
× 2200 Ω)
load
maxon motor control
EPOS2 Positioning Controller
