ACP Functions and Specification
8

ACP Components

Inside the packaged box of the ACP, there are the components as in the following drawing.
Open the packaged box of the ACP, and check if all of the corresponding components are in-
cluded.
Power Supply Adaptor
Input: 100~240V
AC 50/60Hz 3.33A
Output: DC 12V
3.33A, 40W MAX
NOTE
!
• Power Supply Adaptor and Power Cord are not included in PQCPC22A1 or PQCPC22N1.
PQCPC22A0
ACP
(Advanced Control Platform)
Power Cord
