Operating ACP with ACCS
16
1 Air conditioner operation status window
In the air conditioner operation status window, operation status, operation mode, temperature of
the space where the indoor unit is currently installed, and desired temperature of individual air
conditioner are displayed.
Group name & Operation status lamp
At the top of the air conditioner operation status window, the name of the selected group and
the status of individual air conditioner are displayed with the lamps.
The operation status of maximum of 16 air conditioners is displayed in one screen.
Lamp indicates the status of the air conditioner with the color of the lamp. The status of the air
conditioner according to each color is as follows.
Lamp color
Status
(Green)
(Gray)
On
It indicates that the air conditioner is operating normally.
Off
It indicates that the air conditioner is stopped.
Description
