Danfoss VLT AutomationDrive FC 360 Quick Manual page 7

Introduction
1.6.2 Exploded Views
3
4
1 NLCP (accessory)
2 Control cassette
3 RFI switch (screw M3x12 only)
4 Removable fan assembly
5 Grounding clamp (accessory)
6 Screened cable grounding clamp and strain relief (accessory)
7 Motor terminals (U, V, W), and brake and load sharing terminals
8 PE ground
9 3-pole relay 1
Illustration 1.2 Exploded View, J1–J5 (0.37–22 kW), IP20
MG06A602
Quick Guide
1
2
6
5
10
11
12
13
14
15
16
17
Danfoss A/S © 04/2015 All rights reserved.
14
13
12
11
10
9
8
7
2-pole relay 2 (0.37–7.5 kW), pluggable
3-pole relay 2 (11–22 kW), pluggable
Mains terminals
Cable strain relief (accessory for 0.37–2.2 kW units)
Pluggable RS485 terminal
Fixed I/O terminals
Fixed I/O terminals
Terminal cover
B options (MCB 102/MCB 103 accessories)
1 1
17
16
15
5
