No. Description
47 24 V supply low
AMA check U and I
51
nom nom
52 AMA low I
nom
53 AMA big motor
54 AMA small motor
55 AMA parameter range
56 AMA interrupt
57 AMA timeout
58 AMA internal
59 Current limit
61 Encoder loss
63 Mechanical brake low
65 Control card temp
67 Option change
69 Power card temp
80 Drive initialised to default value
87 Auto DC braking
88 Option detection
90 Feedback monitor
95 Broken belt
101 Flow/pressure information
missing
120 Position control fault
250 New spare part
251 New type code
252 Tension limit
nw
Not while running
run
Err. A wrong password was entered
Table 7.1 Warnings and Alarms Code List
1) These faults may be caused by mains distortions. Installing a Danfoss line filter may rectify this problem.
For diagnosis, read out the alarm words, warning words, and extended status words.
MG06A602
Quick Guide
Warning Alarm Trip lock
X X X
X
X
X
X
X
X
X
X
X X
X X
X
X X X
X
X X X
X
X
X X
X X
X X
X X
X
X X
X X
X
Danfoss A/S © 04/2015 All rights reserved.
Cause
24 V DC may be overloaded.
Wrong setting for motor voltage and/or motor current.
Motor current is too low. Check the settings.
The power size of the motor is too large for the AMA to
operate.
The power size of the motor is too small for the AMA to
operate.
The parameter values of the motor are outside of the
acceptable range. AMA does not run.
The AMA is interrupted.
Contact Danfoss.
Frequency converter overload.
Actual motor current has not exceeded release brake-
current within start delay-time window.
The cut-out temperature of the control card is 80 °C.
A new option is detected or a mounted option is
removed.
All parameter settings are initialised to default settings.
Occurs in IT mains when the frequency converter coasts
and the DC voltage is higher than 830 V. Energy on DC-
link is consumed by the motor. This function can be
enabled/disabled in parameter 0-07 Auto DC Braking.
The option is removed successfully.
A feedback fault is detected by option B.
Parameter can only be changed when the motor is
stopped.
Occurs when using a wrong password for changing a
password-protected parameter.
