Application Examples
6.1.4 External Alarm Reset
FC
+24 V 12
D IN 18
D IN 19
COM 20
D IN 27
D IN 29
D IN 32
D IN 33
+10 V 50
A IN
53
A IN
54
COM
55
A OUT
42
Table 6.7 External Alarm Reset
6.1.5 Motor Thermistor
NOTICE
To meet PELV insulation requirements, use reinforced or
double insulation on the thermistors.
FC
+24 V 12
D IN 18
D IN 19
COM 20
D IN 27
D IN 29
D IN 32
D IN 33
+10 V 50
A IN
53
A IN
54
COM
55
A OUT
42
Table 6.8 Motor Thermistor
MG06A602
Quick Guide
Parameters
Function Setting
Parameter 5-11 T
erminal 19 [1] Reset
Digital Input
*=Default value
Notes/comments:
Parameters
Function Setting
Parameter 1-90 [2]
Motor Thermal Thermistor
Protection trip
Parameter 1-93 T [1] Analog
hermistor Source input 53
Parameter 6-19 T
erminal 53 mode [1] Voltage
* = Default value
Notes/comments:
If only a warning is needed, set
parameter 1-90 Motor Thermal
Protection to [1] Thermistor
warning.
Danfoss A/S © 04/2015 All rights reserved.
6.1.6 SLC
FC
+24 V 12
D IN 18
D IN 19
COM 20
D IN 27
D IN 29
D IN 32
D IN 33
+10 V 50
A IN
53
A IN
54
COM
55
A OUT
42
01
02
03
Table 6.9 Using SLC to Set a Relay
Parameters
Function Setting
Parameter 4-30
Motor Feedback [1] Warning
Loss Function
Parameter 4-31
Motor Feedback 100
Speed Error
Parameter 4-32
Motor Feedback 5 s
Loss Timeout
Parameter 7-00 S
peed PID [2] MCB 102
Feedback Source
Parameter 17-11
1024*
Resolution (PPR)
Parameter 13-00
SL Controller [1] On
Mode
Parameter 13-01
[19] Warning
Start Event
Parameter 13-02 [44] Reset
Stop Event key
Parameter 13-10
[21] Warning
Comparator
no.
Operand
Parameter 13-11
Comparator [1] ≈*
Operator
Parameter 13-12
Comparator 90
Value
Parameter 13-51
[22]
SL Controller
Comparator 0
Event
Parameter 13-52 [32] Set
SL Controller digital out A
Action low
Parameter 5-40 F [80] SL digital
unction Relay output A
* = Default value
41
