Introduction
1 1
1.6.1 Enclosure Types and Power Ratings
Enclosure size
380–480 V
Power size
[kW]
Dimensions
[mm]
Height A
Width B
Depth C
(with option B)
a
b
Mounting screw
Table 1.1 Enclosure Sizes, Power Ratings, and Dimensions
4
®
VLT
J1 J2
0.37–2.2 3.0–5.5
210 272.5
75 90
168 (173) 168 (173)
198 260
60 70
M4 M5
Danfoss A/S © 04/2015 All rights reserved.
AutomationDrive FC 360
J3 J4
7.5 11–15
B
b
272.5 317.5
115 133
168 (173) 245 (250)
Mounting holes
260 297.5
90 105
M5 M6
J5 J6
18.5–22 30–45
C
410 515
150 233
245 (250) 241
390 495
120 200
M6 M8
J7
55–75
550
308
323
521
270
M8
