1 Start Here
In This Chapter

About the RadioLinx Industrial 802.11abg Serial and Ethernet Client

Package Contents ................................................................................. 10

System Requirements ........................................................................... 11

Install the IH Browser Configuration Tool .............................................. 12

Install ProSoft Wireless Designer .......................................................... 12

Planning the Network ............................................................................ 12

Configuring the Radios .......................................................................... 15

Verify Communication ........................................................................... 22
For most applications, the installation and configuration steps described in the
following topics will work without additional programming. ProSoft Technology
strongly recommends that you complete the steps in this chapter before
developing a custom application.
1.1

About the RadioLinx Industrial 802.11abg Serial and Ethernet Client

The RadioLinx
a high-speed wireless Ethernet client, with PoE and Serial Encapsulation. The
RLXIB-IESC operates at speeds up to 54 Mbps, using the IEEE 802.11b/g (2.4
GHz band) and 802.11a (5 GHz band) standards. Designed for global
installations, the RLXIB-IESC offers many Industrial features including hazardous
location certifications, OFDM for noise immunity, OPC server diagnostics,
extended temperature, high vibration/shock and DIN-rail mounting.
ProSoft Technology, Inc.
May 25, 2010
®
Industrial 802.11abg Ethernet and Serial Client (RLXIB-IESC) is
RadioLinx® Industrial 802.11abg Serial and Ethernet Client
RLXIB-IESC ♦ 802.11a, b, g
