1.7.6 Save the Radio Configuration
Before closing the Radio Configuration window, you must apply your changes.
Click Apply Changes to save your configuration and restart the radio.
Note: To discard your changes and start over, click Cancel Changes.
1.8

Verify Communication

When configured, the name of each radio is preceded by an M (for Master), an R
(for Repeater), or a C (for Client) in the IH Browser window.
Look at the LEDs to ensure good link quality, as explained in LED display (page
26). After a repeater is configured, you can unplug the Ethernet cable from it.
