RLXIB-IESC ♦ 802.11a, b, g
RadioLinx® Industrial 802.11abg Serial and Ethernet Client
1.1.1 Specifications
Radio
Frequency Band
(Varies by country)
Wireless Standards
Transmit Power (Programmable)
(varies by country)
Channel data rates (Modulation)
Receiver Sensitivity (Typical)
Channels Selection
Security
Physical
Enclosure
Size
Ethernet Ports
Antenna Ports
Weight
Environmental
Operating Temperature
Humidity
External Power
PoE Injector
Average Power
Page 10 of 98
802.11b/g:
2.412 to 2.462 GHz (FCC)
2.412 to 2.472 GHz (ETSI)
802.11a:
5.150 to 5.250 GHz (FCC/ETSI)
5.725 to 5.850 GHz (FCC)
802.11a, 802.11b, 802.11g, 802.11i
Up to 50 mW without amplifier
Up to 500 mW with optional amplifier. (not applicable for
hazardous locations)
802.11b: 11, 5.5, 2, 1 Mbps
(DSSS - BPSK, QPSK, CCK)
802.11g: 54, 48, 36, 24, 18, 12, 9, 6 Mbps (OFDM)
802.11a: 54, 48, 36, 24, 18, 12, 9, 6 Mbps (OFDM)
-90 dBm @ 1 Mbps
-85 dBm @ 11 Mbps
-82 dBm @ 24 Mbps
-75 dBm @ 54 Mbps
1 to 13 (802.11b/g)
36, 40, 44, 48, 149, 153, 157, 161, 165 (802.11a)
WPA2 - 802.11i with 128 bit AES-CCM
Legacy WPA TKIP, WEP support
MAC ID filter
Admin password
Extruded aluminum with DIN and panel mount
114.3 x 116.8 x 44.45 mm (W x H x D)
4.5 x 4.6 x 1.75 inches
One 10/100 Base-T connector, shielded RJ45
IEEE 802.3, 802.3u, 802.3x
(2) RP-SMA connectors
1.06 lbs (479g)
-30° C to +60° C
To 90% RH, non-condensing
10 to 24 VDC
48 VDC
<6W
