Reference
User Manual
Approved antenna table
You can use the following approved antennas when the radio module is
connected directly to an antenna. Refer to Approved antennas with power amp
(page 90) for a table of approved antennas with bi-directional power amplifiers.
Type
1/2 Wave
1/2 Wave art.
Collinear Array
Collinear Array, art. Omni
Collinear Array
Collinear Array
Collinear Array
Collinear Array
Patch
Patch
Patch
Patch*
Yagi
Parabolic*
Parabolic*
Parabolic*
* Only allowed in a point-to-point network.
Approved antennas in Europe/CE
The gain of the antenna connected to the main antenna port, minus the antenna
cable loss, must be less than 4 dB to stay below the 100-mW EIRP transmit
power limit.
The AUX port is only used to receive; it never transmits.
Note: In France, the user is responsible for ensuring that the selected frequency channels comply
with French regulatory standards. At the time of this printing, only channels 10 through 13 can be
used in France.
Approved antennas in Mexico
The gain of the antenna connected to the main antenna port, minus the antenna
cable loss, must be less than 12 dB to stay below the 650-mW EIRP transmit
power limit.
Note: In Mexico, the user is responsible for ensuring that the selected frequency channels comply
with Mexican regulatory standards. At the time of this printing, only channels 9 through 11 can be
used outdoors (1 through 8 cannot); however, channels 1 through 11 can all be used indoors.
ProSoft Technology, Inc.
May 25, 2010
Pattern Gain Connector
Omni 2 dB SMA-RP
Omni 2 dB SMA-RP
Omni 3 dB SMA-RP
5 dB SMA-RP
Omni 5 dB SMA-RP
Omni 8 dB N-RP
Omni 9 dB N-RP
Omni 12 dB N-RP
Directional 8 dB SMA-RP
Directional 11 dB SMA-RP
Directional 13 dB N-RP
Directional 19 dB N-RP
Directional 14 dB N-RP
Directional 15 dB N-RP
Directional 19 dB N-RP
Directional 24 dB N-RP
RadioLinx® Industrial 802.11abg Serial and Ethernet Client
Size (cm)
7H x 1.5
10H x 1.0
6H x 3.0
19H x 1.0
19H x 1.0
43H x 1.6
43H x 1.6
106H x 4.0
15.0H x 15.0
22H x 12.7
22H x 22
15.5 x 15.5
81L x 9.0
40H x 51W x 25D
58H x 66W x 26D
78H x 96W x 29D
RLXIB-IESC ♦ 802.11a, b, g
Min. distance
from Body
20 cm
20 cm
20 cm
20 cm
20 cm
20 cm
20 cm
25 cm
20 cm
22 cm
28 cm
57 cm
28 cm
36 cm
57 cm
100 cm
