ProSoft RadioLinx RLXIB-IESC User Manual page 16

RLXIB-IESC ♦ 802.11a, b, g
RadioLinx® Industrial 802.11abg Serial and Ethernet Client
8 Set Up a Repeater. Return to the RLX-IH Browser. To be sure that you are
seeing the latest status of the radio(s), go to the toolbar (page 71) and click
the "Clear" icon (eraser) followed by the "Scan" icon (binoculars). Double-
click the listing of the next radio to be configured, and configure it as a
repeater radio.
9 Save the Radio Configuration. (page 22) Save the repeater radio settings by
clicking Apply Changes at the bottom of the Radio Settings screen. Repeat
steps 7 through 9 to configure each repeater in the network.
10 After configuring the network and its radios, physically label each radio.
Labeling eliminates confusion about which radios correspond with which
radio configurations in the software. You should identify the radio's name,
network SSID, and IP address, if set.
11 Install the radios and antennas (page 23).
The remainder of the topics in this section describe each of these steps in more
detail.
1.7.1 Start IH Browser
1 Click the S
T
ECHNOLOGY
Page 16 of 98
button, and then navigate to P
TART
/ P S
ROGRAMS RO OFT
ProSoft Technology, Inc.
Start Here
User Manual
May 25, 2010
