RLXIB-IESC ♦ 802.11a, b, g
RadioLinx® Industrial 802.11abg Serial and Ethernet Client
1.4
Install the IH Browser Configuration Tool
1
Insert the ProSoft Solutions CD in your CD-ROM drive. On most computers,
a menu screen will open automatically. If you do not see a menu within a few
seconds, follow these steps:
a
Click the Start button, and then choose Run.
b In the Run dialog box, click the Browse button.
c
In the Browse dialog box, click "My Computer". In the list of drives,
choose the CD-ROM drive where you inserted the ProSoft Solutions CD.
d Select the file prosoft.exe, and then click Open.
e
On the Run dialog box, click OK.
2
On the CD-ROM menu, select IH Browser for the RLX-IHx and RLXIB-x
Products. This action opens the Setup Wizard for IH Browser.
3
Follow the instructions on the installation wizard to install the program with its
default location and settings.
4
Follow the instructions on the installation wizard to install the program with its
default location and settings.
5
When the installation finishes, you may be prompted to restart your computer
if certain files were in use during installation. The updated files will be
installed during the restart process.
1.5
Install ProSoft Wireless Designer
1
On the CD-ROM, navigate to the folder containing ProSoft Wireless
Designer, and then double-click the file S
installation wizard.
2
Follow the instructions on the installation wizard to install the program.
3
Click F
INISH
computer, save your work in any applications that are running, close the
applications, and allow the computer to restart.
1.6
Planning the Network
Before you configure and install the network, you should create a plan for it. The
following points assume that you are creating a bridge network of masters and
repeaters, but you can also set up clients to work with devices on existing
wireless LANs. For information, see Set Up a Client.
To begin, determine where you need radios and then choose locations for them
accordingly. For example, you might decide to install your master radio near a
PC in a central plant location (You can use the PC to configure the radios
through the Radio Configuration / Diagnostic Utility). If the plant is an oil refinery,
for example, you might decide to install radios near the oil tanks.
The next important issue is how to link the radios. Unless the radios are very
close together, you must make sure that each pair of radio antennas in the
network has a line of sight between them. In other words, you must be able to
see from one antenna to another, either with the naked eye or binoculars.
Page 12 of 98
to complete the installation. If you are prompted to restart your
.
. This action starts the
ETUP
EXE
ProSoft Technology, Inc.
Start Here
User Manual
May 25, 2010
