If a DHCP server is not available, the radio will not be able to acquire an IP
address automatically, therefore you must assign an IP address, subnet mask
and default gateway to the radio so that it can communicate on the network.
You can also assign a Static (fixed or permanent) IP address to the radio to
make it easier to identify and configure the radio. Static IP addresses are
particularly useful when configuring radios to serve as Access Points, or for
radios that must be accessible through a firewall.
A detailed discussion of TCP/IP networking is beyond the scope of this manual.
Refer to the following Microsoft knowledgebase article for more information:
http://support.microsoft.com/kb/164015
4.4.1 SNMP Agent settings
This configuration page opens when you click the SNMP button on the Radio
Configuration form.
SNMP is a network management protocol that is often used with TCP/IP and
Ethernet. As an alternative to using the Radio Configuration / Diagnostic Utility,
you can change radio settings and view diagnostics in an SNMP manager
application, if necessary.
Field
Enable
Allow Any Manager
Allow IP
Community String
Permission
Read only
Read/Write
Save
Cancel
The RLXIB-IESC SNMP agent supports SNMP protocol version 1.4 and 2 MIBs:
RFC12133-MIB (partial; internet.mgmt.MIB-2.system, .interfaces, .snmp)
ROMAP-MIB (included on the CD; internet.private.enterprises.romap)
Page 54 of 98
Description
Click this button to enable the following SNMP Agent settings.
Select this option to allow any user to change the radio settings from
any computer using SNMP.
Select this setting to restrict access to an SNMP manager with a
particular IP address, then enter the IP address in the Allow IP field.
Enter a "community string" (essentially a password) that a manager
must use to access the radio's SNMP agent.
Select the permission level to assign to this radio.
An SNMP Agent can view but cannot modify radio settings.
An SNMP Agent can view and modify radio settings.
Saves your changes and updates the radio configuration.
Discards your changes without updating the radio configuration.
