ProSoft RadioLinx RLXIB-IESC User Manual page 19

Start Here
User Manual
To assign a temporary IP Address
1 In IH Browser, click to select the radio.
Tip: If a radio listing does not appear in the window, open the File menu and choose Scan. If you
still do not see a radio listing, refer to Diagnostics and troubleshooting (page 28) in the RLXIB-
IESC User Manual.
2 Open the Operations menu, and choose Assign IP. This action opens the
Assign Temporary IP Address dialog box.
3 Select one of the unused IP addresses, and then click OK.
For information, see Radio Access settings (page 52).
1.7.5 Set Up the Client Radio
To configure the radio, double click on the radio (Radio1) in the IH Browser
window. This action opens a web browser (for example Microsoft Internet
Explorer or Firefox) and loads the IH Radio's web configuration interface.
Important: The radio configuration is protected by a login password. The default password for the
radio is "password" (lower case, no quotes). To prevent unauthorized access to the radio
configuration, you should change the password when you have finished the initial configuration.
ProSoft Technology, Inc.
May 25, 2010
RadioLinx® Industrial 802.11abg Serial and Ethernet Client
RLXIB-IESC ♦ 802.11a, b, g
Page 19 of 98
