RadioLinx Industrial Hotspot Browser
User Manual
Field
Channel
Security
5.5

View Menu

The View menu contains the following commands:
5.5.1 Tool Bar
The Tool Bar near the top of the IH Browser window contains buttons to access
frequently used commands. Hold the mouse button over each button to view a
brief "Tool Tip" explaining the button's use.
5.5.2 Status Bar
The Status Bar at the bottom of the RLX IH Browser displays additional
information about the currently selected menu command or tool bar button. On
the right side of the Status Bar, you can see the status of the Caps Lock and
Num Lock keys on your computer keyboard. Use the corner of the status bar to
drag and resize the RLX-IH Browser window.
ProSoft Technology, Inc.
May 25, 2010
RadioLinx® Industrial 802.11abg Serial and Ethernet Client
Description
The channel that the radio is using, if connected. The channel list
indicates the channel number as well as the frequency (2.4 gHz or 5
gHz).
Important: The RLXIB-IESC radio is supplied with a dual-band antenna
that supports both frequency ranges. If you use a different antenna with
the RLXIB-IESC radio, you must choose a channel and frequency
range supported by the antenna.
Indicates the encryption setting on the radio. See Security settings for
information.
RLXIB-IESC ♦ 802.11a, b, g
Page 71 of 98
